300 脳 63 mm LVL 鈥� TYPICAL SPECIFICATIONS
Cross-section鈥冣��0 mm wide 脳 63 mm deep (11 戮 脳 2 陆 in.)
Length range鈥冣��4 m 鈥� 7.2 m ex-stock; 9.5 m by special order
Grade / Certification鈥僂14 (鈮� F17) to AS/NZS 4357
Residential floor span example 63 脳 300 mm LVL Beam
300 脳 63 mm @ 400 mm joist spacing, 2.0 kPa live + 0.5 kPa dead, L/300 deflection
Single-span鈥冣増 7.2 m (23.6 ft)
Continuous鈥冣増 8.0 m (26.2 ft)
Treatment / exposure
H2S glue-line treatment standard (dry interior south of Tropic of Capricorn)
H3.1 LOSP or untreated available to order.
Handling & fixing 63 脳 300 mm LVL Beam
鈥� 63 脳 300 mm LVL Beam Chamfered edges for splinter-free handling
鈥� 63 脳 300 mm LVL Beam Easily sawn & nailed with standard carpentry tools
鈥� 63 脳 300 mm LVL Beam Minimum bearing 30 mm; end-seal any site cuts
鈥� 63 脳 300 mm LVL Beam Use 90 mm width for built-up beams or high shear zones

Specify 300 脳 63 mm LVL when you need a light-weight, long-span, straight member that replaces steel or hardwood in load-bearing walls, floors or roof beams鈥攚ithout the weight or on-site grading uncertainty of solid timber.
